     1  # Deploying a Retro Arcade
     2
     3  ## Introduction
     4
     5  In previous tutorials, we learned how to [create a package](./0-creating-a-jackal-package.md), [initialize a cluster](./1-initializing-a-k8s-cluster.md), and [deploy a package](./2-deploying-jackal-packages.md). In this tutorial, we will leverage all that past work and deploy a fun application onto your cluster.
     6
     7  ## System Requirements
     8
     9  - You'll need an internet connection to grab the Jackal Package for the games example.
    10
    11  ## Prerequisites
    12
    13  Before beginning this tutorial you will need the following:
    14
    15  - The [Jackal](https://github.com/Racer159/jackal) repository cloned: ([git clone instructions](https://docs.github.com/en/repositories/creating-and-managing-repositories/cloning-a-repository))
    16  - Jackal binary installed on your $PATH: ([Installing Jackal](../1-getting-started/index.md#installing-jackal))
    17  - [An initialized cluster](./1-initializing-a-k8s-cluster.md)
    18
    19  ## YouTube Tutorial
    20  [![Deploying Packages with Jackal Video on YouTube](../.images/tutorials/package_deploy_thumbnail.jpg)](https://youtu.be/7hDK4ew_bTo "Deploying Packages with Jackal")
    21
    22  ## Deploying the Arcade
    23
    24  1. The `dos-games` package is easily deployable via `oci://` by running `jackal package deploy oci://defenseunicorns/dos-games:1.0.0-$(uname -m) --key=https://jackal.dev/cosign.pub`.
    25
    26  :::tip
    27
    28  You can publish your own packages for deployment too via `oci://`.  See the [Store and Deploy Packages with OCI](./7-publish-and-deploy.md) tutorial for more information.
    29
    30  :::
    31
    32  <iframe src="/docs/tutorials/package_deploy_deploy.html" width="100%" height="595px"></iframe>
    33
    34  2. If you did not use the `--confirm` flag to automatically confirm that you want to deploy this package, press `y` for yes.  Then hit the `enter` key.
    35
    36  <iframe src="/docs/tutorials/package_deploy_deploy_bottom.html" width="100%" height="400px"></iframe>
    37
    38  ### Connecting to the Games
    39
    40  When the games package finishes deploying, you should get an output that lists a couple of new commands that you can use to connect to the games. These new commands were defined by the creators of the games package to make it easier to access the games. By typing the new command, your browser should automatically open up and connect to the application we just deployed into the cluster, using the `jackal connect` command.
    41
    42  <iframe src="/docs/tutorials/package_deploy_connect.html" width="100%"></iframe>
    43
    44  ![Connected to the Games](../.images/tutorials/games_connected.png)
    45
    46  :::note
    47  If your browser doesn't automatically open up, you can manually go to your browser and copy the IP address that the command printed out into the URL bar.
    48  :::
    49
    50  :::note
    51  The `jackal connect games` will continue running in the background until you close the connection by pressing the `ctrl + c` (`control + c` on a mac) in your terminal to terminate the process.
    52  :::
    53
    54  ## Removal
    55
    56  1. Use the `jackal package list` command to get a list of the installed packages.  This will give you the name of the games package to remove it.
    57
    58  <iframe src="/docs/tutorials/package_deploy_list.html" height="120px" width="100%"></iframe>
    59
    60  2. Use the `jackal package remove` command to remove the `dos-games` package.  Don't forget the `--confirm` flag.  Otherwise you'll receive an error.
    61
    62  <iframe src="/docs/tutorials/package_deploy_remove_no_confirm.html" width="100%" height="425px"></iframe>
    63
    64  3. You can also use the `jackal package remove` command with the jackal package file, to remove the package.  Again don't forget the `--confirm` flag.
    65
    66  <iframe src="/docs/tutorials/package_deploy_remove_by_file.html" height="100px" width="100%"></iframe>
    67
    68  The dos-games package has now been removed from your cluster.
    69
    70  ## Troubleshooting
    71
    72  ### Unable to connect to the Kubernetes cluster
    73
    74  <iframe src="/docs/tutorials/troubleshoot_unreachable.html" width="100%" height="200px"></iframe>
    75
    76  :::info Remediation
    77
    78  If you receive this error, either you don't have a Kubernetes cluster, your cluster is down, or your cluster is unreachable.
    79
    80  1. Check your kubectl configuration, then try again.  For more information about kubectl configuration see [Configure Access to Multiple Clusters](https://kubernetes.io/docs/tasks/access-application-cluster/configure-access-multiple-clusters/) from the Kubernetes documentation.
    81
    82  If you need to setup a cluster, you can perform the following.
    83
    84  1. Deploy a Kubernetes cluster with the [Creating a K8s Cluster with Jackal](./5-creating-a-k8s-cluster-with-jackal.md) tutorial.
    85  2. Perform the [Initialize a cluster](./1-initializing-a-k8s-cluster.md) tutorial.
    86
    87  After that you can try deploying the package again.
    88
    89  :::
    90
    91  ### Secrets "jackal-state" not found
    92
    93  <iframe src="/docs/tutorials/troubleshoot_uninitialized.html" width="100%" height="250px"></iframe>
    94
    95  :::info Remediation
    96
    97  If you receive this error when jackal is attempting to deploy the `BASELINE COMPONENT`, this means you have not initialized the kubernetes cluster.  This is one of the prerequisites for this tutorial.  Perform the [Initialize a cluster](./1-initializing-a-k8s-cluster.md) tutorial, then try again.
    98
    99  :::
   100
   101  ## Credits
   102
   103  :sparkles: Special thanks to these fine references! :sparkles:
   104
   105  - <https://www.reddit.com/r/programming/comments/nap4pt/dos_gaming_in_docker/>
   106  - <https://earthly.dev/blog/dos-gaming-in-docker/>
