github.com/brahmaroutu/docker@v1.2.1-0.20160809185609-eb28dde01f16/docs/extend/plugins_authorization.md (about) 1 <!--[metadata]> 2 +++ 3 title = "Access authorization plugin" 4 description = "How to create authorization plugins to manage access control to your Docker daemon." 5 keywords = ["security, authorization, authentication, docker, documentation, plugin, extend"] 6 aliases = ["/engine/extend/authorization/"] 7 [menu.main] 8 parent = "engine_extend" 9 weight = -1 10 +++ 11 <![end-metadata]--> 12 13 14 # Create an authorization plugin 15 16 Docker's out-of-the-box authorization model is all or nothing. Any user with 17 permission to access the Docker daemon can run any Docker client command. The 18 same is true for callers using Docker's remote API to contact the daemon. If you 19 require greater access control, you can create authorization plugins and add 20 them to your Docker daemon configuration. Using an authorization plugin, a 21 Docker administrator can configure granular access policies for managing access 22 to Docker daemon. 23 24 Anyone with the appropriate skills can develop an authorization plugin. These 25 skills, at their most basic, are knowledge of Docker, understanding of REST, and 26 sound programming knowledge. This document describes the architecture, state, 27 and methods information available to an authorization plugin developer. 28 29 ## Basic principles 30 31 Docker's [plugin infrastructure](plugin_api.md) enables 32 extending Docker by loading, removing and communicating with 33 third-party components using a generic API. The access authorization subsystem 34 was built using this mechanism. 35 36 Using this subsystem, you don't need to rebuild the Docker daemon to add an 37 authorization plugin. You can add a plugin to an installed Docker daemon. You do 38 need to restart the Docker daemon to add a new plugin. 39 40 An authorization plugin approves or denies requests to the Docker daemon based 41 on both the current authentication context and the command context. The 42 authentication context contains all user details and the authentication method. 43 The command context contains all the relevant request data. 44 45 Authorization plugins must follow the rules described in [Docker Plugin API](plugin_api.md). 46 Each plugin must reside within directories described under the 47 [Plugin discovery](plugin_api.md#plugin-discovery) section. 48 49 **Note**: the abbreviations `AuthZ` and `AuthN` mean authorization and authentication 50 respectively. 51 52 ## Default user authorization mechanism 53 54 If TLS is enabled in the [Docker daemon](../security/https.md), the default user authorization flow extracts the user details from the certificate subject name. 55 That is, the `User` field is set to the client certificate subject common name, and the `AuthenticationMethod` field is set to `TLS`. 56 57 ## Basic architecture 58 59 You are responsible for registering your plugin as part of the Docker daemon 60 startup. You can install multiple plugins and chain them together. This chain 61 can be ordered. Each request to the daemon passes in order through the chain. 62 Only when all the plugins grant access to the resource, is the access granted. 63 64 When an HTTP request is made to the Docker daemon through the CLI or via the 65 remote API, the authentication subsystem passes the request to the installed 66 authentication plugin(s). The request contains the user (caller) and command 67 context. The plugin is responsible for deciding whether to allow or deny the 68 request. 69 70 The sequence diagrams below depict an allow and deny authorization flow: 71 72  73 74  75 76 Each request sent to the plugin includes the authenticated user, the HTTP 77 headers, and the request/response body. Only the user name and the 78 authentication method used are passed to the plugin. Most importantly, no user 79 credentials or tokens are passed. Finally, not all request/response bodies 80 are sent to the authorization plugin. Only those request/response bodies where 81 the `Content-Type` is either `text/*` or `application/json` are sent. 82 83 For commands that can potentially hijack the HTTP connection (`HTTP 84 Upgrade`), such as `exec`, the authorization plugin is only called for the 85 initial HTTP requests. Once the plugin approves the command, authorization is 86 not applied to the rest of the flow. Specifically, the streaming data is not 87 passed to the authorization plugins. For commands that return chunked HTTP 88 response, such as `logs` and `events`, only the HTTP request is sent to the 89 authorization plugins. 90 91 During request/response processing, some authorization flows might 92 need to do additional queries to the Docker daemon. To complete such flows, 93 plugins can call the daemon API similar to a regular user. To enable these 94 additional queries, the plugin must provide the means for an administrator to 95 configure proper authentication and security policies. 96 97 ## Docker client flows 98 99 To enable and configure the authorization plugin, the plugin developer must 100 support the Docker client interactions detailed in this section. 101 102 ### Setting up Docker daemon 103 104 Enable the authorization plugin with a dedicated command line flag in the 105 `--authorization-plugin=PLUGIN_ID` format. The flag supplies a `PLUGIN_ID` 106 value. This value can be the plugin’s socket or a path to a specification file. 107 Authorization plugins can be loaded without restarting the daemon. Refer 108 to the [`dockerd` documentation](../reference/commandline/dockerd.md#configuration-reloading) for more information. 109 110 ```bash 111 $ docker daemon --authorization-plugin=plugin1 --authorization-plugin=plugin2,... 112 ``` 113 114 Docker's authorization subsystem supports multiple `--authorization-plugin` parameters. 115 116 ### Calling authorized command (allow) 117 118 ```bash 119 $ docker pull centos 120 ... 121 f1b10cd84249: Pull complete 122 ... 123 ``` 124 125 ### Calling unauthorized command (deny) 126 127 ```bash 128 $ docker pull centos 129 ... 130 docker: Error response from daemon: authorization denied by plugin PLUGIN_NAME: volumes are not allowed. 131 ``` 132 133 ### Error from plugins 134 135 ```bash 136 $ docker pull centos 137 ... 138 docker: Error response from daemon: plugin PLUGIN_NAME failed with error: AuthZPlugin.AuthZReq: Cannot connect to the Docker daemon. Is the docker daemon running on this host?. 139 ``` 140 141 ## API schema and implementation 142 143 In addition to Docker's standard plugin registration method, each plugin 144 should implement the following two methods: 145 146 * `/AuthZPlugin.AuthZReq` This authorize request method is called before the Docker daemon processes the client request. 147 148 * `/AuthZPlugin.AuthZRes` This authorize response method is called before the response is returned from Docker daemon to the client. 149 150 #### /AuthZPlugin.AuthZReq 151 152 **Request**: 153 154 ```json 155 { 156 "User": "The user identification", 157 "UserAuthNMethod": "The authentication method used", 158 "RequestMethod": "The HTTP method", 159 "RequestURI": "The HTTP request URI", 160 "RequestBody": "Byte array containing the raw HTTP request body", 161 "RequestHeader": "Byte array containing the raw HTTP request header as a map[string][]string " 162 } 163 ``` 164 165 **Response**: 166 167 ```json 168 { 169 "Allow": "Determined whether the user is allowed or not", 170 "Msg": "The authorization message", 171 "Err": "The error message if things go wrong" 172 } 173 ``` 174 #### /AuthZPlugin.AuthZRes 175 176 **Request**: 177 178 ```json 179 { 180 "User": "The user identification", 181 "UserAuthNMethod": "The authentication method used", 182 "RequestMethod": "The HTTP method", 183 "RequestURI": "The HTTP request URI", 184 "RequestBody": "Byte array containing the raw HTTP request body", 185 "RequestHeader": "Byte array containing the raw HTTP request header as a map[string][]string", 186 "ResponseBody": "Byte array containing the raw HTTP response body", 187 "ResponseHeader": "Byte array containing the raw HTTP response header as a map[string][]string", 188 "ResponseStatusCode":"Response status code" 189 } 190 ``` 191 192 **Response**: 193 194 ```json 195 { 196 "Allow": "Determined whether the user is allowed or not", 197 "Msg": "The authorization message", 198 "Err": "The error message if things go wrong" 199 } 200 ``` 201 202 ### Request authorization 203 204 Each plugin must support two request authorization messages formats, one from the daemon to the plugin and then from the plugin to the daemon. The tables below detail the content expected in each message. 205 206 #### Daemon -> Plugin 207 208 Name | Type | Description 209 -----------------------|-------------------|------------------------------------------------------- 210 User | string | The user identification 211 Authentication method | string | The authentication method used 212 Request method | enum | The HTTP method (GET/DELETE/POST) 213 Request URI | string | The HTTP request URI including API version (e.g., v.1.17/containers/json) 214 Request headers | map[string]string | Request headers as key value pairs (without the authorization header) 215 Request body | []byte | Raw request body 216 217 218 #### Plugin -> Daemon 219 220 Name | Type | Description 221 --------|--------|---------------------------------------------------------------------------------- 222 Allow | bool | Boolean value indicating whether the request is allowed or denied 223 Msg | string | Authorization message (will be returned to the client in case the access is denied) 224 Err | string | Error message (will be returned to the client in case the plugin encounter an error. The string value supplied may appear in logs, so should not include confidential information) 225 226 ### Response authorization 227 228 The plugin must support two authorization messages formats, one from the daemon to the plugin and then from the plugin to the daemon. The tables below detail the content expected in each message. 229 230 #### Daemon -> Plugin 231 232 233 Name | Type | Description 234 ----------------------- |------------------ |---------------------------------------------------- 235 User | string | The user identification 236 Authentication method | string | The authentication method used 237 Request method | string | The HTTP method (GET/DELETE/POST) 238 Request URI | string | The HTTP request URI including API version (e.g., v.1.17/containers/json) 239 Request headers | map[string]string | Request headers as key value pairs (without the authorization header) 240 Request body | []byte | Raw request body 241 Response status code | int | Status code from the docker daemon 242 Response headers | map[string]string | Response headers as key value pairs 243 Response body | []byte | Raw docker daemon response body 244 245 246 #### Plugin -> Daemon 247 248 Name | Type | Description 249 --------|--------|---------------------------------------------------------------------------------- 250 Allow | bool | Boolean value indicating whether the response is allowed or denied 251 Msg | string | Authorization message (will be returned to the client in case the access is denied) 252 Err | string | Error message (will be returned to the client in case the plugin encounter an error. The string value supplied may appear in logs, so should not include confidential information)
