github.com/gocrane/crane@v0.11.0/docs/installation.md (about) 1 # Installation 2 3 ## Prerequisites 4 5 - Kubernetes 1.18+ 6 - Helm 3.1.0 7 8 ## Steps 9 10 ### Helm Installation 11 12 Please refer to Helm's [documentation](https://helm.sh/docs/intro/install/) for installation. 13 14 ### Installing prometheus and grafana with helm chart 15 16 !!! note 17 If you already deployed prometheus, grafana in your environment, then skip this step. 18 19 !!! Warning "Network Problems" 20 If your network is hard to connect GitHub resources, you can try the mirror repo. Like GitHub Release, GitHub Raw Content `raw.githubusercontent.com`. 21 22 But mirror repo has a certain **latency**.[Mirror Repo](mirror.md) 23 24 Crane use prometheus to be the default metric provider. 25 26 Using following command to install prometheus components: prometheus-server, node-exporter, kube-state-metrics. 27 28 === "Main" 29 30 ```bash 31 helm repo add prometheus-community https://prometheus-community.github.io/helm-charts 32 helm install prometheus -n crane-system \ 33 --set pushgateway.enabled=false \ 34 --set alertmanager.enabled=false \ 35 --set server.persistentVolume.enabled=false \ 36 -f https://raw.githubusercontent.com/gocrane/helm-charts/main/integration/prometheus/override_values.yaml \ 37 --create-namespace prometheus-community/prometheus 38 ``` 39 40 === "Mirror" 41 42 ```bash 43 helm repo add prometheus-community https://finops-helm.pkg.coding.net/gocrane/prometheus-community 44 helm install prometheus -n crane-system \ 45 --set pushgateway.enabled=false \ 46 --set alertmanager.enabled=false \ 47 --set server.persistentVolume.enabled=false \ 48 -f https://gitee.com/finops/helm-charts/raw/main/integration/prometheus/override_values.yaml \ 49 --create-namespace prometheus-community/prometheus 50 ``` 51 Fadvisor use grafana to present cost estimates. Using following command to install a grafana. 52 53 54 === "Main" 55 56 ```bash 57 helm repo add grafana https://grafana.github.io/helm-charts 58 helm install grafana \ 59 -f https://raw.githubusercontent.com/gocrane/helm-charts/main/integration/grafana/override_values.yaml \ 60 -n crane-system \ 61 --create-namespace grafana/grafana 62 ``` 63 64 === "Mirror" 65 66 ```bash 67 helm repo add grafana https://finops-helm.pkg.coding.net/gocrane/grafana 68 helm install grafana \ 69 -f https://gitee.com/finops/helm-charts/raw/main/integration/grafana/override_values.yaml \ 70 -n crane-system \ 71 --create-namespace grafana/grafana 72 ``` 73 74 ### Deploying Crane and Fadvisor 75 76 77 === "Main" 78 79 ```bash 80 helm repo add crane https://gocrane.github.io/helm-charts 81 helm install crane -n crane-system --create-namespace crane/crane 82 helm install fadvisor -n crane-system --create-namespace crane/fadvisor 83 ``` 84 85 === "Mirror" 86 87 ```bash 88 helm repo add crane https://finops-helm.pkg.coding.net/gocrane/gocrane 89 helm install crane -n crane-system --create-namespace crane/crane 90 helm install fadvisor -n crane-system --create-namespace crane/fadvisor 91 ``` 92 93 ### Deploying Crane-scheduler(optional) 94 ```bash 95 helm install scheduler -n crane-system --create-namespace crane/scheduler 96 ``` 97 98 ### Verify Installation 99 100 Check deployments are all available by running: 101 102 ```bash 103 kubectl get deploy -n crane-system 104 ``` 105 106 The output is similar to: 107 ```bash 108 NAME READY STATUS RESTARTS AGE 109 crane-agent-8h7df 1/1 Running 0 119m 110 crane-agent-8qf5n 1/1 Running 0 119m 111 crane-agent-h9h5d 1/1 Running 0 119m 112 craned-5c69c684d8-dxmhw 2/2 Running 0 20m 113 grafana-7fddd867b4-kdxv2 1/1 Running 0 41m 114 metric-adapter-94b6f75b-k8h7z 1/1 Running 0 119m 115 prometheus-kube-state-metrics-6dbc9cd6c9-dfmkw 1/1 Running 0 45m 116 prometheus-node-exporter-bfv74 1/1 Running 0 45m 117 prometheus-node-exporter-s6zps 1/1 Running 0 45m 118 prometheus-node-exporter-x5rnm 1/1 Running 0 45m 119 prometheus-server-5966b646fd-g9vxl 2/2 Running 0 45m 120 ``` 121 122 you can see [this](https://github.com/gocrane/helm-charts) to learn more. 123 124 ## Customize Installation 125 126 Deploy `Crane` by apply YAML declaration. 127 128 === "Main" 129 130 ```bash 131 git clone https://github.com/gocrane/crane.git 132 CRANE_LATEST_VERSION=$(curl -s https://api.github.com/repos/gocrane/crane/releases/latest | grep -oP '"tag_name": "\K(.*)(?=")') 133 git checkout $CRANE_LATEST_VERSION 134 kubectl apply -f deploy/manifests 135 kubectl apply -f deploy/craned 136 kubectl apply -f deploy/metric-adapter 137 ``` 138 139 === "Mirror" 140 141 ```bash 142 git clone https://e.coding.net/finops/gocrane/crane.git 143 CRANE_LATEST_VERSION=$(curl -s https://api.github.com/repos/gocrane/crane/releases/latest | grep -oP '"tag_name": "\K(.*)(?=")') 144 git checkout $CRANE_LATEST_VERSION 145 kubectl apply -f deploy/manifests 146 kubectl apply -f deploy/craned 147 kubectl apply -f deploy/metric-adapter 148 ``` 149 150 The following command will configure prometheus http address for crane if you want to customize it. Specify `CUSTOMIZE_PROMETHEUS` if you have existing prometheus server. 151 152 ```bash 153 export CUSTOMIZE_PROMETHEUS= 154 if [ $CUSTOMIZE_PROMETHEUS ]; then sed -i '' "s/http:\/\/prometheus-server.crane-system.svc.cluster.local:8080/${CUSTOMIZE_PROMETHEUS}/" deploy/craned/deployment.yaml ; fi 155 ``` 156 157 ## Access Dashboard 158 159 You can use the dashboard to view and manage crane manifests. 160 161  162 163 ### Port Forward 164 165 Easy access to the dashboard through `kubectl port-forward`. 166 167 ```bash 168 kubectl -n crane-system port-forward service/craned 9090:9090 169 ``` 170 171 ### NodePort 172 173 ```bash 174 # Change service type 175 kubectl patch svc craned -n crane-system -p '{"spec": {"type": "NodePort"}}' 176 ``` 177 178 ```bash 179 # Get Dashboard link base on your cluster configuration 180 PORT=$(kubectl get svc -n crane-system craned -o jsonpath='{.spec.ports[?(@.name == "dashboard-service")].nodePort}') 181 NODE_IP=$(kubectl get node -ojsonpath='{.items[].status.addresses[?(@.type == "InternalIP")].address}') 182 echo "Dashboard link: http://${NODE_IP}:${PORT}" 183 ``` 184 185 ### LoadBalancer 186 187 188 #### Quick Start 189 190 ```bash 191 # Change service type 192 kubectl patch svc craned -n crane-system -p '{"spec": {"type": "LoadBalancer"}}' 193 ``` 194 195 #### Example 196 197 ```log 198 $ kubectl patch svc craned -n crane-system -p '{"spec": {"type": "LoadBalancer"}}' 199 200 service/craned patched 201 202 $ kubectl get svc -n crane-system craned 203 NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE 204 craned LoadBalancer 10.101.123.74 10.200.0.4 443:30908/TCP,8082:32426/TCP,9090:31331/TCP,8080:31072/TCP 57m 205 206 # Access dashboard via 10.200.0.4:9090 207 ``` 208 209 ### Ingress 210 211 #### kubernetes/ingress-nginx 212 213 If the cluster version is < 1.19, you can create the ingress resources like this: 214 215 ```yaml 216 apiVersion: networking.k8s.io/v1beta1 217 kind: Ingress 218 metadata: 219 name: ingress-crane-dashboard 220 namespace: crane-system 221 spec: 222 ingressClassName: nginx 223 rules: 224 - host: dashboard.gocrane.io # change to your domain 225 http: 226 paths: 227 - path: / 228 backend: 229 serviceName: craned 230 servicePort: 9090 231 ``` 232 233 If the cluster uses Kubernetes version >= 1.19.x, then its suggested to create the second ingress resources, using yaml examples shown below. 234 235 These examples are in conformity with the `networking.kubernetes.io/v1` api. 236 237 ```yaml 238 apiVersion: networking.k8s.io/v1 239 kind: Ingress 240 metadata: 241 name: ingress-crane-dashboard 242 namespace: crane-system 243 spec: 244 rules: 245 - host: dashboard.gocrane.io # change to your domain 246 http: 247 paths: 248 - path: / 249 pathType: Prefix 250 backend: 251 service: 252 name: craned 253 port: 254 number: 9090 255 ingressClassName: nginx 256 ``` 257 258 Example: 259 260 ```log 261 $ kubectl get svc -n ingress-nginx 262 NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE 263 ingress-nginx-controller LoadBalancer 10.102.235.229 10.200.0.5 80:32568/TCP,443:30144/TCP 91m 264 ingress-nginx-controller-admission ClusterIP 10.102.49.240 <none> 443/TCP 91m 265 266 $ curl -H "Host: dashboard.gocrane.io" 10.200.0.5 267 <!DOCTYPE html> 268 <html lang="en"> 269 <head> 270 <meta charset="UTF-8" /> 271 <meta name="viewport" content="width=device-width, initial-scale=1.0" /> 272 <title>Crane Dashboard</title> 273 ................................................................ 274 ``` 275 276 #### Traefik 277 278 ```yaml 279 apiVersion: traefik.containo.us/v1alpha1 280 kind: IngressRoute 281 metadata: 282 name: dashboard-crane-ingress 283 namespace: crane-system 284 spec: 285 entryPoints: 286 - web 287 routes: 288 - kind: Rule 289 match: Host(`dashboard.gocrane.io`) 290 services: 291 - name: craned 292 port: 9090 293 ``` 294 295 ```log 296 $ kubectl get svc -n traefik-v2 297 NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE 298 traefik LoadBalancer 10.107.109.44 10.200.0.6 80:30102/TCP,443:30139/TCP 16m 299 300 $ curl -H "Host: dashboard.gocrane.io" 10.200.0.6 301 <!DOCTYPE html> 302 <html lang="en"> 303 <head> 304 <meta charset="UTF-8" /> 305 <meta name="viewport" content="width=device-width, initial-scale=1.0" /> 306 <title>Crane Dashboard</title> 307 ................................................................ 308 ``` 309 310 ## Get your Kubernetes Cost Report 311 312 Get the Grafana URL to visit by running these commands in the same shell: 313 314 ```bash 315 export POD_NAME=$(kubectl get pods --namespace crane-system -l "app.kubernetes.io/name=grafana,app.kubernetes.io/instance=grafana" -o jsonpath="{.items[0].metadata.name}") 316 kubectl --namespace crane-system port-forward $POD_NAME 3000 317 ``` 318 319 visit [Cost Report](http://127.0.0.1:3000/dashboards) here with account(admin:admin).
